供水管道標識樁常見印字

Common printing of water supply pipeline identification pile

給水管道標識樁樁體常見為印制管道方LOGO及電話，字體一般印制”給水管道、嚴禁開挖“、”下有自來水管道、嚴禁開挖“、”供水管道、嚴禁開挖“、”下有供水管道、嚴禁開挖“

The water supply pipeline identification pile is usually printed with the logo and telephone of the pipeline owner, and the font is generally printed with "water supply pipeline, no excavation", "water supply pipeline, no excavation", "water supply pipeline, no excavation", "water supply pipeline, no excavation", "water supply pipeline, no excavation", and no excavation“

供水管道標識樁設置規范

Code for setting of water supply pipeline marker posts

高壓和超高壓管道（P＞1.6MPa）必須設置標識樁。其他壓力級制管道可設置標識樁。標識樁宜采用塑料或其他非金屬符合材料。標識樁設置的位置和間距應符合下列規定：

High pressure and ultra-high pressure pipelines (P ＞ 1.6Mpa) must be provided with identification piles. Other pressure grade pipelines can be provided with identification piles. Identification piles should be made of plastic or other non-metallic materials. The location and spacing of marker posts shall meet the following requirements:

標識樁應安裝在管道的正上方，當標識樁用作轉角樁時，應安裝在轉角段中點的正上方。當管道正上方沒有安裝條件時，可設置在相對距離教近的路邊綠化帶內，并在標識樁上標明管樁。

The identification pile shall be installed directly above the pipe. When the identification pile is used as a corner pile, it shall be installed directly above the midpoint of the corner section. When there is no installation condition directly above the pipeline, it can be set in the roadside green belt relatively close to the church, and the pipe pile shall be marked on the identification pile.

全封閉禁入道路不得設置標識樁。

No sign post shall be set on the completely closed road.

標識樁的安裝間距宜為100m.地面平坦、視礙少、管道路由順直的情況，標識樁的安裝間距可大于100m.特殊地段，事故多發地段可以縮短安裝間距。

The installation spacing of identification piles should be 100m If the ground is flat, there are few visual obstacles and the pipeline route is straight, the installation spacing of identification piles can be greater than 100m In special sections and accident prone sections, the installation spacing can be shortened.

標識樁的正面應包含警示用語并面向道路。

The front of the sign pile shall contain warning words and face the road.

標識樁的形狀應符合下列規定：

The shape of the identification pile shall meet the following requirements:

高壓和超高壓管道標識樁應為立方體，由樁和樁帽組成。

High pressure and ultra-high pressure pipe identification piles shall be cubes consisting of piles and pile caps.

其他壓力級制管道標識樁應為三角形柱體。

Other pressure class pipe identification piles shall be triangular columns.

標識樁的尺寸可按以下規定選取。立方體標識樁的尺寸為150mm×150mm×1000mm.等邊三角形柱體標識樁的尺寸為b×h:150mm×1000mm.

The size of identification pile can be selected according to the following provisions. The size of the cube marker post is 150mm × 150mm × 1000mm. The dimension of the equilateral triangle column identification pile is b × h:150mm × 1000mm.

標識樁的內容必須包含管道權屬單位名稱、警示用語、聯系電話。

The contents of the identification pile must include the name of the pipeline ownership unit, warning words and contact number.

供水標識樁的內容可包括標識樁編號、壓力管道使用登記編號、管道區域名稱、企業標識等。

The contents of water supply identification pile may include identification pile number, pressure pipe use registration number, pipeline area name, enterprise identification, etc.
